Outdoor P5 LED Display Module Waterproof Panels India
When it comes to outdoor advertising, stadium screens, or large-format public displays, image clarity and durability matter more than anything else. That’s exactly where an outdoor P5 LED display module proves its worth. At Romio Technologies, we manufacture and supply outdoor LED display modules built for Indian weather conditions heavy rain, dust storms, and direct summer sun without ever compromising on picture quality.
As a company that has been supplying LED display solutions pan India, we understand that customers don’t just want a screen they want a module that keeps working flawlessly for years. In this guide, we’ll walk you through everything about our outdoor P5 LED display module specifications, size, pricing in India, and why it’s one of the most preferred choices for outdoor LED screens today.
What Is an Outdoor P5 LED Display Module?
An outdoor P5 LED display module is an LED panel where the distance between two adjacent pixels (called pixel pitch) is 5mm. This pixel pitch strikes a good balance between cost and picture sharpness, which is why it’s widely used for billboards, stadium perimeter screens, retail storefronts, and transportation hub displays across India.
Because the pixels are placed closer together compared to larger pitch modules (like P8 or P10), an outdoor P5 LED display module produces sharper text and cleaner video playback, even when viewers are standing relatively close to the screen. At the same time, it remains bright enough to stay visible from a distance in open, sunlit areas making it a favourite for both close-range and far-range outdoor viewing.
Multiple outdoor P5 LED display modules are joined together, cabinet by cabinet, to build one large seamless outdoor screen whether that’s a compact storefront sign or a massive stadium display.
Outdoor P5 LED Display Module Specifications
| Specification | Details |
|---|---|
| Model | RT-O-P5 |
| Panel Size | 320mm (W) × 160mm (H) |
| Pixel Pitch | P5 (5mm) |
| Pixel Resolution | 64 × 32 Dots |
| Pixel Density | 40,000 Dots/m² |
| LED Configuration | SMD RGB 3-in-1 (1R1G1B) |
| Brightness | 5500 Nits |
| Refresh Rate | 7680Hz |
| Scan Mode | Constant Current, 1/8 Scan |
| Waterproof Rating | IP65 (Front & Rear Waterproof) |
| Viewing Angle | 140°–160° (Horizontal & Vertical) |
| Contrast Ratio | 5000:1 |
| Driver IC | ICN2037 / ICN2053 / ICN2038S |
| Control Options | Wi-Fi, 4G & Wired Ethernet |
| Operating Environment | Outdoor |
| Maintenance Type | Front & Rear Maintenance |
| Power Supply | AC 110V–240V, 50/60Hz |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +70°C |
| Accessories Included | Power Cable, Data/Signal Cable & Waterproof Rubber Rings |
| Application | Outdoor Advertising, Billboards, Stadiums, Events, Retail Stores, Government Projects, Transportation Hubs |
| Warranty | 3 Years Onsite Warranty (Pan India) |
Why These Specifications Matter
Ultra-High Brightness (5500 Nits): Outdoor modules face direct sunlight for most of the day. A brightness level of 5500 nits ensures your content stays fully visible even at noon, without fading or washing out.
7680Hz Refresh Rate: A high refresh rate eliminates flickering and banding when the module is captured on camera this matters a lot for stadiums, event stages, and locations where the display will be filmed or photographed.
IP65 Waterproofing: Both the front and rear of the outdoor P5 LED display module are sealed against water and dust ingress, so it keeps performing during monsoon season without any risk of short circuits or panel damage.
SMD 3-in-1 LED Technology: This packs the red, green, and blue LEDs into a single unit, giving smoother colour blending, wider viewing angles, and a more uniform look compared to older DIP-style LEDs.
Outdoor P5 LED Display Module Size
The standard panel size for our outdoor P5 LED display module is 320mm x 160mm, following the common industry sizing so that it fits standard cabinet frames and mounting brackets with matching screw holes. This standard size makes installation, replacement, and future maintenance much simpler, since modules can be swapped without needing custom fabrication.
For large-format installations — such as big advertising hoardings, building facades, or stadium screens multiple outdoor P5 LED display modules are combined to form one seamless display of any required size, whether it’s a small 3ft x 2ft signage board or a massive 40ft wide billboard.
Outdoor P5 LED Display Module Key Features
Where Is the Outdoor P5 LED Display Module Used?
- Outdoor advertising billboards and hoardings
- Stadiums and sports arenas (perimeter and scoreboard displays)
- Shopping malls and retail storefronts
- Airports, railway stations, and metro stations
- Concert stages and event backdrops
- Government and public information display boards
- Corporate building facades
Because it balances cost, brightness, and clarity so well, the outdoor P5 LED display module has become one of the most requested options among businesses searching for a dependable outdoor LED screen for medium to large outdoor projects.
Outdoor P5 LED Display Module Price in India
Pricing for an outdoor P5 LED display module depends on a few factors:
1. Order quantity – Bulk orders typically bring the per-module cost down.
2. Cabinet type – Whether you need a simple flat panel or a full cabinet with structural framing.
3. Installation location – Site accessibility and structural requirements (wall-mounted, pole-mounted, or standalone structure) can affect the total project cost.
4. Control system – Basic sending/receiving cards versus advanced Wi-Fi/5G-enabled control systems.
5. After-sales support – Onsite installation, training, and warranty coverage.
Because outdoor LED display pricing varies significantly by project size and site conditions, we recommend getting a customised quotation rather than relying on a generic price list.
Our team at Romio Technologies provides transparent, itemised quotations after understanding your screen size, location, and content requirements so you know exactly what you’re paying for, with no hidden costs.
Get in touch with our team for the latest outdoor P5 LED display module
price in India, based on your project specifications.
Why Choose Romio Technologies for Your Outdoor P5 LED Display Module?
Experience Across India: We’ve supplied and installed outdoor LED display modules across multiple states, adapting our products to different climate and site conditions — from humid coastal regions to dry, dusty interiors.
Quality-Tested Modules: Every outdoor P5 LED display module is tested for waterproofing, brightness uniformity, and colour consistency before it leaves our facility.
Transparent Warranty: Our 3-year onsite warranty means our support team comes to you, rather than asking you to ship modules back and forth for repairs.
End-to-End Support: From site survey and structural design to installation and after-sales maintenance, our team manages the entire project so you don’t have to coordinate with multiple vendors.
Local Manufacturing Advantage: Being based in India allows us to offer faster turnaround times, easier warranty servicing, and pricing that’s more competitive than imported alternatives.
If you’re comparing vendors for an outdoor LED project, feel free to ask us for site references or past installation photos we’re happy to share real project examples relevant to your industry.
An Outdoor P5 LED Display Module is a waterproof LED panel with a 5mm pixel pitch, sized 320mm x 160mm, offering 5500 nits brightness and IP65 protection. It’s used for outdoor billboards, stadiums, and public displays, delivering sharp, sunlight-readable visuals with a high refresh rate for smooth video playback.
